Power Amplifier MORGAN SOUND P6.2

P6.2 Specification:
Output Power: 20-20KHz, 1W with 1 KHz
8Ω Stereo Power(RMS): 2400WX2
4Ω Stereo Power(RMS): 4400WX2
2Ω Stereo Power(RMS): 7000WX2
8Ω Bridged Power(RMS): 8000W
4Ω Bridged Power(RMS): 14000W

Frequency Response(+o/-0.3dB, 1W/8Ω ): 20 Hz – 34 KHz
THD 20 Hz – 20 KHz for 1 W <0.1%
Signal-to-Noise Ratio: >112 dBA
Channel separation (Crosstalk) at 1 KHz: >70 dB
Input Connectors (per channel): 3-pin XLR, electronically balanced
Output Connectors (per channel): Binding Posts 2-pole
Class: TD
TourClass Protection: ACL, IGM, AutoRamp, short circuit, DC voltage, turn-on/off transient, current inrush, sub/ultrasonic input

Operating voltage 230 V / 115 V nominal: 130-265 V / 65-135 V selectable
Voltage Gain(dB): 23, 26, 29, 32, 35, 38, 41, 44 dB selectable
Input impedance: 20 kOhm
Level adjustment (per CH. ): Front-panel potentiometer, 31 position detented from -inf to 0 dB
Dimensions (WxHxD): 483x88x396mm
Packing dimension: 560x180x500mm
Net weight(kg): 15
Gross weight(kg): 18
