MORGAN SOUND XC48 PRO Digital Speaker Processor: Professional DSP Crossover

MORGAN SOUND XC48 PRO – Professional Digital Speaker Processor 4 In 8 Out DSP Crossover

The MORGAN SOUND XC48 PRO is a high-performance digital speaker processor engineered for professional live sound, touring systems, theaters, conference halls, and fixed installations.
Built around a powerful 96kHz DSP platform, it delivers precise crossover management, advanced dynamics control, and flexible matrix routing in a compact 1U chassis.

🔹 High-Resolution Audio Performance

96kHz sampling frequency
32-bit DSP processor
24-bit A/D and D/A converters
Frequency response: 19.7Hz – 20kHz (±0.5dB)
Signal-to-noise ratio >118dB
THD <0.002% (0dBu / 1kHz) Channel separation >106dB
CMRR >71dB
Maximum input level: +21.5dBu

The XC48 PRO ensures exceptional clarity, ultra-low distortion, and wide dynamic range for demanding professional audio systems.

🔹 Flexible Speaker Management Configurations

Each output channel allows independent input selection or matrix mixing of multiple inputs, making it ideal for multi-zone systems, line arrays, and complex installations.

🔹 Advanced EQ and Dynamics Processing

Input Processing
12-band parametric EQ per input

2 dynamic EQ per input

Independent noise gate
Dedicated compressor
Automatic Gain Control (AGC)
Delay up to 1000ms
Gain range: -80dB to +12dB
Polarity reverse
Independent mute
Output Processing
15-band parametric EQ per output
Independent HPF & LPF crossover

Filter types: Linkwitz-Riley / Bessel / Butterworth
Slopes up to 48dB/oct
Dedicated compressor and limiter per channel
Delay up to 1000ms
Parameter copy between channels
All EQ sections provide 241 selectable frequency points from 19.7Hz to 20kHz with ultra-fine bandwidth adjustment (0.01 octave resolution).

🔹 Comprehensive Connectivity and System Control MORGAN SOUND XC48 PRO

USB 3.0 PC control interface
Dual RS485 ports (RJ45)
Supports up to 250 devices in one network
Remote control distance over 1500 meters
Compatible with central control systems
Internet remote control via optional UTWR1 interface
The processor can be operated via the front-panel encoder or intuitive PC software.

🔹 Display and Preset Management

2×24 blue backlit LCD display
5-segment LED meters for precise input/output monitoring
60 user presets
Independent password protection for input, output, and system settings
Panel lock function for secure operation

🔹 Built-in Signal Generator

Integrated test signals include:
White noise
Pink noise
Sine wave
Frequency sweep
Ideal for system tuning and speaker alignment.

🔹 Physical Specifications

Dimensions: 482 × 228 × 44mm (1U rack size)
Net weight: 4.25kg
Power consumption: ≤25W
Power supply: AC 110V / 220V, 50/60Hz
